Double Cylinders 4 Column Fabric Hydraulic Die Cutting Machine Manual

Place of Origin JIANGSU ,CHINA
Brand Name YAOYU
Certification CE
Model Number XCLP3-50
Minimum Order Quantity 1 SET
Packaging Details WOODEN CASE
Delivery Time 30 days
Product Details
Parameter Can Be Customized Applicable Industries Manufacturing Plant, Home Use
Packaging Type Case Voltage 380V, 220V, Customizable
Max Cutting Force 60TON, 80TON, 100TON, 200TON, Customizable Driven Type Hydraulic
High Light

Manual Hydraulic Die Cutting Machine


Double Cylinders Hydraulic Die Cutting Machine


Double Cylinders Hydraulic Die Cutter

Leave a Message
Product Description

Hg-A30t Four Column Manual Hydraulic Die Cutting Machine Fabric


Features and Advantages:

1. Double-cylinders,four-columns,self-balancing connecting rod which can maintain equal pressure of each position.
2. Series B machine has the long-stroke setting for adopt to the jumbo-size materials and high knife mould cutting.
3. When the upper board pressure down and contact to the blade,automatically,it can cut slowly,so that there is no size error between the top and the bottom materials.
4. The unique setting construction,combine with the cutting knife and cutting height which stroke simple and accurate.
5. Central automatic lubrication systems can ensure precision and durability of the machine.
6. More economical and 2 or 3 times improving producting capacity.
7. Suitable for single-layer or multi-layer sheet or roll materials.


Key Points:

Conveyor Belt: Germany or Switzerland Made or Customizable

Oil Pump: Germany Made or Customizable

Special Hydraulic System lowers the operation noise

Sealing Ring: Made in Italy, Customizable
Press Switch: Made in Italy, Customizable
Cutting Switch: Made in Germany, Customizable


Hydraulic Cutting Machine For Making Shoes




Model number XCLP3-50
Maximum cutting force 50T
Upper pressure plate to table distance 50-200 ㎜
The cutting area 1600×800 ㎜
1400×800 ㎜
Main motor power 4KW
Machine weight 4000KG


Note:The company can customize the special specifications such as cutting zone, feeding mode (single, bilateral automatic feeding) according to customer's requirements.



This machine is suitable for all kinds of non - metal sheet metal materials to be cut or half - cut.

For example: plastic, pearl cotton packaging, rubber, printing and other industries.



1. PLC programmable control, simple operation, fast and accurate.

2. The main engine adopts double oil cylinder, double crank automatic balance connecting rod balance and four-column precision guide mechanism to ensure the cutting depth of each cutting position is exactly the same.

3. When pressing the pressing plate, it is automatically slow to cut the cutting, so that there is no size error between the top and bottom of the cutting material.

4. All sliding parts are lubricated by hydraulic system, reducing wear and tear, ensuring the service life and precision of the machine.

5. The automatic feeding mechanism of the bilateral motor adopts the frequency conversion buffer system, which can simultaneously cut the different height of the cutter to improve the efficiency of the work 80%.

6. Can configure the cutting board micro device, make the cutting board uniform consumption, cost saving.

7. It can be equipped with die clamping device, and it is convenient and fast to replace the die.

Double Cylinders 4 Column Fabric Hydraulic Die Cutting Machine Manual 0

Double Cylinders 4 Column Fabric Hydraulic Die Cutting Machine Manual 1

Double Cylinders 4 Column Fabric Hydraulic Die Cutting Machine Manual 2
